Description
Camden CX-33 Door Control Logic Relay
SPDT Door Control Logic Relay with 3-Segment LED Display
The Camden CX-33 Door Control Logic Relay is a flexible access control relay module designed to support complex door control, sequencing, timing, and output logic applications. Operating on 12 to 30 Volt AC/DC, the CX-33 provides dependable relay control for commercial access control systems, automatic doors, security entrances, vestibules, maglock applications, request-to-exit devices, and other controlled opening solutions.
With 13 different operating modes, available sub-modes, and adjustable timers on each relay, the CX-33 gives installers near-limitless configuration options for solving real-world door control challenges. Its 5 inputs, including a wet input, provide added flexibility for sequencing from multiple points while maintaining and holding different outputs as required by the application.
Designed for easier setup and field programming, the large 3-segment LED display is simple to view and understand, while the 3-button mode selection interface helps technicians quickly configure operating modes, timing functions, and relay behavior without unnecessary complexity.
Advanced Door Logic Made Easier
The Camden CX-33 is built for installations that require more than a basic relay. From timed door releases and delayed locking to vestibule sequencing, multi-input control, and custom door logic, this relay provides the flexibility needed to manage demanding access control applications.
Its intuitive display, adjustable timers, and multiple inputs make it a strong choice for installers who need reliable control, faster setup, and flexible relay logic in one compact module.
Key Features
- SPDT door control logic relay
- 13 operating modes with sub-modes
- Adjustable timers on each relay
- 5 inputs, including a wet input
- Sequences from multiple points
- Maintains and holds different outputs
- Large 3-segment LED display
- 3-button mode selection
- 12 to 30 Volt AC/DC operation
- 105 mA current draw
Common Applications
- Access control door sequencing
- Maglock and electric strike control
- Request-to-exit device integration
- Automatic door control logic
- Vestibule and interlock applications
- Delayed egress support applications
- Multi-input relay control systems
- Commercial security door installations
