Description
DSC HSM2HOST9 PowerG 2-Way Wireless Transceiver Module
The DSC HSM2HOST9 is a PowerG 2-way wireless transceiver module designed to add PowerG wireless device support to compatible DSC security systems. Operating at 915 MHz, the HSM2HOST9 provides reliable two-way communication between a compatible DSC control panel and enrolled PowerG sensors, detectors, wireless keys and other wireless security devices.
Designed for compatible DSC PowerSeries Neo systems, the HSM2HOST9 PowerG transceiver can support up to 128 wireless zones and up to 32 wireless keys, depending on the connected control panel. Its supervised two-way wireless communication makes it an important component for residential and commercial intrusion systems requiring dependable PowerG wireless connectivity.
DSC HSM2HOST9 Key Features
- PowerG 2-way wireless transceiver module
- 915 MHz wireless operation
- Supports compatible DSC PowerG wireless devices
- Up to 128 wireless zones, depending on control panel
- Up to 32 wireless keys, depending on control panel
- Two-way supervised wireless communication
- Compatible with DSC PowerSeries Neo systems
- Compatible with the DSC PG9920 PowerG repeater
- 12 Volt DC operation
- 60 mA current draw
Why Choose the DSC HSM2HOST9?
The DSC HSM2HOST9 provides the wireless communication interface needed to connect compatible PowerG devices to supported DSC security control equipment.
PowerG technology uses two-way communication so enrolled devices can communicate with the security system rather than simply transmitting one-way signals. This helps provide dependable device supervision and communication throughout the protected premises.
For larger buildings or installations with challenging wireless conditions, the HSM2HOST9 can also be used with a compatible DSC PG9920 PowerG repeater to extend wireless coverage.
Typical Applications
- DSC PowerSeries Neo security systems
- Residential intrusion detection systems
- Commercial security installations
- Wireless motion detection
- Wireless door and window protection
- Wireless key and remote control applications
- PowerG system expansion
- Extended wireless security coverage
PowerG Wireless Communication
The HSM2HOST9 PowerG host transceiver creates the wireless connection between compatible DSC control equipment and enrolled PowerG security devices.
Its 915 MHz two-way wireless communication supports a broad range of compatible PowerG intrusion detection and security accessories while maintaining supervised communication between the panel and wireless devices.
This makes the HSM2HOST9 particularly useful when expanding a wired DSC system with wireless sensors or when installing devices in locations where additional wiring would be difficult or impractical.
DSC HSM2HOST9 Technical Specifications
| Manufacturer | DSC |
| Model / Part Number | HSM2HOST9 |
| Product Type | PowerG 2-Way Wireless Transceiver Module |
| Wireless Technology | PowerG |
| Frequency | 915 MHz |
| Communication | 2-Way Wireless |
| Wireless Zones | Up to 128, depending on control panel |
| Wireless Keys | Up to 32, depending on control panel |
| Input Voltage | 12 Volt DC |
| Current Draw | 60 mA |
| Operating Temperature | 14°F to 131°F (-10°C to 55°C) |
| Dimensions | 6-11/32" x 6-11/32" x 1-31/32" |
| Repeater Compatibility | DSC PG9920 PowerG Repeater |
DSC HSM2HOST9 at a Glance
Choose the DSC HSM2HOST9 when a compatible DSC security system requires 915 MHz PowerG wireless capability. With two-way supervised communication, support for a large number of wireless zones and wireless keys, and compatibility with the PG9920 PowerG repeater, the HSM2HOST9 provides a dependable foundation for expanding a DSC PowerG wireless security system.
